About This Product
| Volume 141 Catalog Page: 104 |
|---|
| 30,000 BTU with 8kW electric heat |
| Suitable for use with R-22 and R-410A refrigerant |
| Check flowrater for cooling-only and heat pump operation |
| Direct-drive, resilient-mount, multi-speed motor |
| Factory-installed pull-type disconnect |
| 3/8-in liquid and 3/4-in suction connections |
| Primary and secondary drain connection in non-metallic pan |
| 49-1/4-in W x 10-in H x 21-in D, 79-lb |
| Additional freight charges will apply for shipments outside our local delivery areas |
| ACNF300816 |
| ADA Compliant: | No |
|---|---|
| Amps: | 41.3A |
| Btu Cool: | 30000 |
| Btu Heat: | 8 kW |
| Connection Type: | 3/4-in Drain |
| Depth: | 21-in |
| Dimension: | 43-1/4" W x 10" H x 21"D |
| Eco Friendly: | No |
| Electric Heat: | 8 kW |
| Energy Star Approved: | No |
| ETL Approved: | Yes |
| Height: | 10-in |
| Liquid Line Set Size: | 3/8-in |
| Log In For Pricing: | Yes |
| Motor - PSC/EEM - Code: | PSC |
| Piston Size: | 6.0999999999999999E-2 |
| Refrigerant Code: | R-22/R-410A |
| Size: | 43-1/4 x 10 x 21 |
| Suction Line Size: | 3/4-in |
| Tons: | 2.5 Ton |
| UL Approved: | No |
| Width: | 49-1/4-in |
